CHAUVIN ARNOUX CA-F403 [31/42] Characteristics
![CHAUVIN ARNOUX CA-F403 [31/42] Characteristics](/views2/1666043/page31/bg1f.png)
31
4 CHARACTERISTICS
4.1 REFERENCE CONDITIONS
Quantities of influence Reference conditions
Temperature: 23°C ±2°C
Relative humidity: 45% to 75%
Supply voltage: 6.0V ±0.5V
Frequency range of the applied signal: 45–65Hz
Sine wave: pure
Peak factor of the applied alternating signal: √2
Position of the conductor in the clamp: centred
Adjacent conductors: none
Alternating magnetic field: none
Electric field: none
4.2 CHARACTERISTICS UNDER THE REFERENCE CONDITIONS
The uncertainties are expressed in ± (x% of the reading (R) + y points (pt)).
4.2.1 DC voltage measurement
Measurement range
0.00V to 99.99V
100.0V to 999.9V
1000V (1)
Specified
measurement range
0 to 100% of the
measurement range
0 to 100% of the
measurement range
Uncertainties
from 0.00V to 9.99V
±(1% R + 10 pt)
from 10.00V to
99.99V
±(1% R +3 pt)
±(1% R +3 pt)
Resolution
0.01V
0.1V
1V
Input impedance
10M
Ω
Note (1) The display indicates "+OL" above + 2 000 V and "-OL"
below – 2 000 V, in REL mode. The "-" and "+" signs are managed.
