1-8 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V_2X2/ATX_12V_2X4
2) ATX
3) CPU_FAN
4) SYS_FAN1/2/3/4
5) SYS_FAN5/6_PUMP
6) CPU_OPT
7) EC_TEMP1/EC_TEMP2
8) LED_C1/LED_C2
9) D_LED1/D_LED2
10
) DLED_V_SW1/DLED_V_SW2
11) SATA3
0/1/2/3/4/5
12) M2A/M2M
13) F_PANEL
14) F_AUDIO
15) SPDIF_O
16) F_USB30C
17) F_USB30
18) F_USB1/F_USB2
19
) TPM
20
) THB_C
21) CLR_CMOS
22) BAT
23) CPU/DRAM/VGA/BOOT
5
8
9
13
2
11
16
1914 9 10
1
1
8
20
12
15
12
18 4
3 106 7
21
22
4
23
17
- 15 -
