Gigabyte Z390 AORUS PRO WIFI (rev. 1.0) [20/56] M2a m2m m socket 3 connectors

Step 1:

Get a screw and a standoff from the included M.2 screw and standoff packs. Locate the M.2 connector

where you will install the M.2 SSD, use a screwdriver to unfasten the screw on the heatsink and then

remove the heatsink.

Step 2:

LocatethepropermountingholefortheM.2SSDtobeinstalledandthentightenthestandoffrst.Insert

the M.2 SSD into the M.2 connector at an angle.

Step 3:

Press the M.2 SSD down and then secure it with the screw. Replace the heatsink and secure it to the

original hole.
