- 25 -
Hardware Installation
1-9 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
4 1
16
13
10
12
158
8
2
49
11
5 7
9
3
14
11
17
11
1) ATX_12V1/ATX_12V2
2) ATX
3) CPU_FAN
4) SYS_FAN1/SYS_FAN2
5)
SYS_FAN5A/B_PUMP/SYS_FAN6A/B_PUMP
6) CPU_OPT
7) EC_TEMP1/EC_TEMP2
8) LED_C1/LED_C2
9) D_LED1/D_LED2
10) SATA3 0/1/2/3/4/5/6/7
11)
M2M/M2Q/M2P
12) F_PANEL
13) F_AUDIO
14) F_U32C
15) F_U32_1/F_U32_2
16) F_USB1/F_USB2
17) TPM
18) BAT
19) NOISE_SENSOR
20) THB_C
21) CLR_CMOS
5
6
7
18
19
21
20
