- 75 -

Unique Features

5-1-3 Using Q-Flash Plus

A. Before you use Q-Flash Plus, follow the steps below in sequence:

1. FromGIGABYTE'swebsite,downloadthelatestcompressedBIOSupdatelethatmatchesyourmotherboard

model.

2. UncompressthedownloadedBIOSle,saveittoyourUSBashdrive,andrenameittoGIGABYTE.bin.

Note:TheUSBashdrivemustusetheFAT32lesystemanditmustbeaUSB2.0ashdrive.

3. InserttheUSBashdriveintotheQ-Flash Plus Port on the back panel.

4. Connect the power cables to the 12V power connector (connect either one if there are two) and main power

connector.

B. Using Q-Flash Plus

Press the Q-Flash Plus button on the back panel and the system will automatically search and match the BIOS

leintheUSBashdriveontheQ-FlashPlusport.TheQ-FlashPlusbuttonwillashduringtheBIOSmatching

andashingprocess.Waitfor2-3minutesandthebuttonwillstopashingwhentheBIOSashingiscomplete.

• Before using the Q-Flash Plus function, make sure that your system is off (S5 shutdown state).

• If your motherboard has a BIOS switch and a SB switch, reset them to their default settings.

(Default setting for the BIOS switch: Boot from the main BIOS; default setting for the SB switch:

Dual BIOS)

• AfterthemainBIOSisashed,thesystemwillrebootautomaticallyandthenDualBIOS

™

will

continue to update the backup BIOS. After completion, the system will reboot again and boot

from the main BIOS.

• Q-Flash Plus will update the main BIOS only if run without the CPU installed. The system will

shut down upon completion.
