- 36 -
Hardware Installation
19) NOISE_SENSOR (Noise Detection Header)
This header can be used to connect a noise detection cable to detect the noise inside the case.
Pin No. Denition
1 Noise Detection
2 GND
Before connecting the cable to the header, make sure to remove the jumper cap; re-place the
jumper cap if the header is not in use.
For more information on the noise detection function, refer to the instructions in Chapter 5, "Unique
Features," "APP Center\System Information Viewer"
Noise Detection
Cable
1
1
20) THB_C (GIGABYTE Add-in Card Connector)
This connector is for a GIGABYTE add-in card.
