Installation
After removing the machine from the packaging, proceed as
follows:
On the back of the machine
1) Unscrew the central screw (A); unscrew the 4 lateral
screws (B) and remove the cross piece (C).
2) Lean the machine forward and remove the plastic bags
containing the two polystyrene blocks at the sides,
pulling downwards.
3) Press the plug (to be found in the envelope with the
instructions) into the hole.
4) Fix the sheet of corrugated material on the
bottom as shown in picture.
5) Use the 4 feet to level the machine with the floor:
a) Turn the nut clockwise to release the screw adjuster of
the foot.
b) Rotate foot to raise or lower it until it stands firmly on the
ground.
c) Lock the foot in position by turning the nut anti-clockwise
until it comes up against the bottom of the machine.
107
Appliance complies with European Directive 89/336/EEC, 73/23/EEC and subsequent
amendments.
Technical data
■
Max. load of dry laundry
■
Water pressure
Measurements
■
Width
■
Depth
■
Height
NB: For specifications regarding electrical data, see the data panel on the front of the washing
machine (porthole area).
6 kg
(0,5 ÷ 10 bar)
0,05 ÷ 1 MPa
60 cm
54 cm
85 cm
Customer Service
The appliance is covered by a certificate of guarantee which allows you free use of the Candy
Technical Support Service. Remember to send off the guarantee certificate for validation
within 10 days of the date of purchase.
You should retain the receipt issued by the retailer when you purchased the machine to show
to the call out engineer, should you need to consult one.
If your washing machine shows signs of a defect or is not working properly, before you contact
GIAS Service we recommend you carry out the checks detailed on page 104 within the
Trouble shooting section.
If the problem with the machine persists after completing all the recommended checks, please
dial the GIAS Service number on the rear cover of this manual.
For the cost of a telephone call, you will be connected directly to GIAS. It is important you tell
the GIAS advisor your product’s model number and serial number, which you will find on the
rating label (16 characters, beginning with the number 3), found on the front of the washing
machine (door area). By doing this, your enquiry will be responded to more efficiently.
106
Fig. 2
A
B
C
Note: we recommend you keep the transverse bracket, braces and
screws to immobilise the machine for future transit. The Manufacturers
will not be responsible for any possible damage to the machine
caused by not following the rules relating to releasing the mechanism.
The user is responsible for all costs of installation.
