• Single Unit • Water cooled chiller, standard efficiency • EWWD-I-SS
1
6
• Hydronic Systems • Single Unit
30
6 Sound data
6 - 1 Sound Level Data
Sound pressure level correction factors for different distances
NSL_1-2_Rev.00_2
EWWD-I-SS
Unit size
Distance
1m 5m 10m 15m 20m 25m
340 0.0 -7.9 -12.7 -15.8 -18.1 -19.8
400 0.0 -7.9 -12.7 -15.8 -18.1 -19.8
460 0.0 -7.9 -12.7 -15.8 -18.1 -19.8
550 0.0 -7.9 -12.7 -15.8 -18.1 -19.8
650 0.0 -7.9 -12.7 -15.8 -18.1 -19.8
700 0.0 -7.5 -12.2 -15.3 -17.5 -19.3
800 0.0 -7.9 -12.7 -15.8 -18.1 -19.8
850 0.0 -7.5 -12.2 -15.3 -17.5 -19.3
900
0.0 -7.5 -12.2 -15.3 -17.5 -19.3
950 0.0 -7.9 -12.7 -15.8 -18.1 -19.8
C10 0.0 -7.5 -12.2 -15.3 -17.5 -19.3
C12 0.0 -7.5 -12.2 -15.3 -17.5 -19.3
C13 0.0 -7.5 -12.2 -15.3 -17.5 -19.3
C14 0.0 -7.5 -12.2 -15.3 -17.5 -19.3
C15 0.0 -7.5 -12.2 -15.3 -17.5 -19.3
C16 0.0 -7.5 -12.2 -15.3 -17.5 -19.3
C17 0.0 -7.5 -12.2
-15.3 -17.5 -19.3
C18 0.0 -7.5 -12.2 -15.3 -17.5 -19.3
EWWD-I-XS
Unit size
Distance
1m 5m 10m 15m 20m 25m
360 0.0 -7.9 -12.7 -15.8 -18.1 -19.8
440 0.0 -7.9 -12.7 -15.8 -18.1 -19.8
500 0.0 -7.9 -12.7 -15.8 -18.1 -19.8
600 0.0 -7.9 -12.7 -15.8 -18.1 -19.8
750 0.0 -7.9 -12.7 -15.8 -18.1 -19.8
800 0.0 -7.5 -12.2 -15.3 -17.5 -19.3
850 0.0 -7.9 -12.7 -15.8 -18.1 -19.8
950 0.0 -7.5 -12.2 -15.3 -17.5 -19.3
C10
0.0 -7.5 -12.2 -15.3 -17.5 -19.3
C11 0.0 -7.9 -12.7 -15.8 -18.1 -19.8
C12 0.0 -7.5 -12.2 -15.3 -17.5 -19.3
