Daikin EWWD800I-SS [38/51] Hydraulic performance
![Daikin EWWD800I-SS [38/51] Hydraulic performance](/views2/1668070/page38/bg26.png)
• Single Unit • Water cooled chiller, standard efficiency • EWWD-I-SS
1
9
• Hydronic Systems • Single Unit
38
9 Hydraulic performance
9 - 2 Partial Heat Recovery Pressure Drop
Partial Heat Recovery pressure drops
OPT_1-2-3-4-5-6-7-8_Rev.00_7
NOTES
Size EWWD~I-SS
340 400 460 550 650 700 800 850 900 950 C10 C12 C13 C14 C15 C16 C17 C18
Heating Capacity (kW)
24.5 27.5 35.5 40 48 51 54 62 70 73 76 92 94.3 97.9 102 105 109 126
Water Flow (l/s)
1.17 1.31 1.70 1.89 2.30 2.43 2.59 2.95 3.33 3.50 3.63 4.38 4.51 4.68 4.87 5.02 5.21 6.02
Heat Recovery Pressure Drops (kPa)
97 103 88 106 90 99 111 91 87 96 98 65 68 73 79 83 89 115
EWWD~I-SS
Water fl ow and pressure drop referred to nominal condition: evaporator water in/out: 12/7°C – condenser water in/out: 30/35°C – water heat recovery in/out 40/45°C
NOTES
Size EWWD~I-XS
360 440 500 600 750 800 850 950 C10 C11 C12
Heating Capacity (kW)
23.8 29.2 33.7 40.2 47.8 52.9 58.3 61.6 66.4 73.4 79.6
Water Flow (l/s)
1.14 1.40 1.61 1.92 2.28 2.53 2.79 2.94 3.17 3.51 3.80
Heat Recovery Pressure Drops (kPa)
17 25 31 44 17 20 25 27 31 37 43
EWWD~I-XS
Water fl ow and pressure drop referred to nominal condition: evaporator water in/out: 12/7°C – condenser water in/out: 30/35°C – water heat recovery in/out 40/45°C
