Low Voltage 2006/95/EC

Electromagnetic Compatibility 2004/108/EC

Electrical & Safety codes EN 60204–1 / EN 60335-2-40

Manufacturing Quality Stds UNI – EN ISO 9001:2004

The unit will be tested at full load in the factory at the nominal working conditions and water temperatures. Before shipment a

full test will be held to avoid any losses.

Chiller will be delivered to the job site completely assembled and charged with right refrigerant and oil quantity.

Comply with the manufacturer instructions for rigging and handling equipment.

The unit will be able to start up and operate as standard at full load and condenser entering fl uid temperature from .… °C to

.… °C with an evaporator leaving fl uid temperature between …. °C and …. °C.

3 Power input for single water cooled screw chiller in cooling mode: ............... kW

3 Shell & tube evaporator entering water temperature in cooling mode: ............... °C

3 Shell & tube evaporator leaving water temperature in cooling mode: ............... °C

3 Shell & tube evaporator water fl ow: ............... l/s

3 Shell & tube condenser entering water temperature in cooling mode: ............... °C

3 Shell & tube condenser leaving water temperature in cooling mode: ............... °C

3 Shell & tube condenser water fl ow: ............... l/s

3 The unit should work with electricity in range 400V ±10%, 3ph, 50Hz without neutral and shall only have one power

connection point.

pressure levels must be rated in accordance to ISO 3744.

Other types of rating unacceptable. Vibration level should not exceed 2 mm/s.

Unit dimensions shall not exceed following indications:

3 unit length ............... mm,

3 unit width ............... mm,

3 unit height ............... mm.
