10 Specification text
10 - 1 Specification Text
SPC_1-2-3_Rev.00_2
CHILLER COMPONENTS
Compressors
3 Semi-hermetic, single-screw type with one main helical rotor meshing with gaterotor. The gaterotor will be constructed
of a carbon impregnated engineered composite material. The gaterotor supports will be constructed of cast iron.
3 The oil injection shall be used in order to get high EER (Energy Effi ciency Ratio) also at high condensing pressure and
low sound pressure levels in each load condition.
3 Refrigerant system differential pressure shall provide oil fl ow throught service replaceble, 0.5 micron, full fl ow, cartridge
type oil fi lter internal to compressor.
3 Refrigerant system differential pressure shall provide oil injection on all moving compressor parts to correctly lubricate
them. Electrical oil pump lubricating system is not acceptable.
3 The compressor’s oil cooling must be realized, when necessary, by refrigerant liquid injection. External dedicated
heat exchanger and additional piping to carry the oil from the compressor to heat exchanger and viceversa will not be
accepted.
3 The compressor shall be provided with an external, high effi ciency, cyclonic type oil separator and with built-in oil fi lter,
cartridge type.
3 The compressor shall be direct electrical driven, without gear transmission between the screw and the electrical motor.
3 Shall be present two thermal protection realized by a thermistor for high temperature protection: one temperature sensor
to protect electrical motor and another sensor to protect unit and lubricating oil from high discharge gas temperature.
3 The compressor shall be equipped with an electric oil-crankcase heater.
3 Compressor shall be fully fi eld serviceable. Compressor that must be removed and returned to the factory for service
shall be unacceptable.
Cooling capacity control system
3 Each unit will have a microprocessor for the control of compressor slide valve’s position and the instantaneous RPM
value of the motor.
3 The unit capacity control shall be infi nitely modulating, from 100% down to 25% for each circuit (from 100% down to
12.5% of full load for unit with 2 compressors and 8.3% for units with 3 compressors). The chiller shall be capable of
stable operation to a minimum of 12.5% of full load without hot gas bypass.
3 Step unloading unacceptable because of evaporator leaving water temperature fl uctuation and low unit effi ciency at
partial load.
3 The system shall stage the unit based on the leaving evaporator water temperature that shall be controlled by a PID
(Proportional Integral Derivative) loop.
3 Unit control logic shall manage frequency level of the compressor electric motor to exactly match plant load request in
order to keep constant the set point for delivered chilled water temperature. In this operating condition unit control logic
shall modulate electrical frequency level in a range lower and upper the nominal electrical network value fi xed at 50 Hz.
3 The microprocessor unit control shall detect conditions that approach protective limits and take self-corrective action
prior to an alarm occurring. The system shall automatically reduce chiller capacity when any of the following parameters
are outside their normal operating range:
o High condenser pressure
o Low evaporation refrigerant temperature
o High compressor motor amps
Evaporator
3 The units shall be supplied with shell and tubes counter-fl ow heat exchanger with single refrigerant pass. It will be
refrigerant direct expansion type with refrigerant inside the tubes and water outside (shell side). It will include carbon
steel tube sheets, with straight copper tubes internally wound for higher effi ciencies, expanded on the tube plates.
3 The evaporator will have 2 circuits, one for each compressor and shall be single refrigerant pass.
3 The water connections shall be VICTAULIC type connections as standard to ensure quick mechanical disconnection
between the unit and the hydronic network.
3 Evaporator is manufactured in accordance to PED approval.
