Daikin EWWD800I-SS [39/51] Hydraulic performance
![Daikin EWWD800I-SS [39/51] Hydraulic performance](/views2/1668070/page39/bg27.png)
3
1
9
• Hydronic Systems • Single Unit
39
• Single Unit • Water cooled chiller, standard efficiency • EWWD-I-SS
9 Hydraulic performance
9 - 3 Total Heat Recovery Pressure Drop
NOTES
Total Heat Recovery pressure drops
OPT_1-2-3-4-5-6-7-8_Rev.00_6
Size EWWD~I-SS
340 400 460 550 650 700 800 850 900 950 C10 C12 C13 C14 C15 C16 C17 C18
Heating Capacity (kW)
388 460 538 630 756 832 919 993 1072 1161 1217 1364 1427 1507 1589 1659 1730 1800
Water Flow (l/s)
18.54 21.98 25.70 30.10 36.12 39.75 43.91 47.44 51.22 55.47 58.15 65.17 68.18 72.00 75.92 79.26 82.66 86
Heat Recovery Pressure Drops (kPa)
26 26 28 25 24 25 26 28 26 23 23 24 24 25 23 23 24 24
EWWD~I-SS
Water fl ow and pressure drop referred to nominal condition: evaporator water in/out: 12/7°C – condenser water in/out: 30/35°C – water heat recovery in/out 40/45°C
OPT_1-2-3-4-5-6-7-8_Rev.00_8
Total and Partial Heat Recovery Pressure Drops
To determinate the pressure drop for different versions or at different working condition, please refer to the following formula:
PD
2
(kPa) = PD
1
(kPa) x
1.80
where:
Q
2
(l/s)
Q
1
(l/s)
PD
2
Pressure drop to be determinated (kPa)
PD
1
Pressure drop at nominal condition (kPa)
Q
2
water fl ow at new working condition (l/s)
Q
1
water fl ow at nominal condition (l/s)
How to use the formula: Example
The unit EWWD360I-XS has been selected for working at the following conditions:
- evaporator water in/out: 12/7°C
- condenser water in/out: 30/35°C
- Partial heat recovery leaving wate
r temperature 45/50°C
The heating capacity at these working conditions is: 13.2 kW
The water fl ow at these working conditions is: 0.63 l/s
The unit EWWD360I-XS at nominal working conditions has the followi
ng data:
- evaporator water in/out: 12/7°C
- condenser water in/out: 30/35°C
- Partial heat recovery leaving water temperature 40/45°C
The heating capacity at these working conditions is: 23.8 kW
The water fl ow at these working conditions is: 1.14 l/s
The pressure drop at these working conditions is: 17 kPa
The pressure drop at the selected working condition will be:
PD
2
(kPa) = 17 (kPa) x
1.80
PD
2
(kPa) = 6 (kPa)
0.63 (l/s)
1.14 (l/s)
