Gigabyte GA-SBC4100 [11/33] Dcin_pwr dc power connector input 9v 36v

2) SYS_FAN (Fan Header)

The fan header on this motherboard is 4-pin. The fan header possesses a foolproof insertion design.

When connecting a fan cable, be sure to connect it in the correct orientation (the black connector wire is

the ground wire). The speed control function requires the use of a fan with fan speed control design. For

optimum heat dissipation, it is recommended that a system fan be installed inside the chassis.

• Be sure to connect fan cables to the fan headers to prevent your CPU and system from

overheating. Overheating may result in damage to the CPU or the system may hang.

• Thesefanheadersarenotcongurationjumperblocks.Donotplaceajumpercapontheheaders.

Pin No. Denition

1 GND

2 DC IN

3 DC IN

4 GND

1
