1-2 ProductSpecications
CPU Built in with an Intel
®
Quad-Core Celeron
®
N4100 SoC (2.4 GHz)
* Do not disassemble the onboard SoC and the heatsinks by yourself to avoid damage
to these components.
4 MB Cache
Memory
2 x DDR4 SO-DIMM socket supporting up to 16 GB of system memory
Support for DDR4 2400/2133 MHz memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and
memory modules.)
Onboard
Graphics
Integrated in the SoC:
- 2 x HDMI ports, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.0 version, HDCP 2.2.
Audio
Realtek
®
ALC255 codec
High Denition Audio
2-channel
LAN 2 x Realtek
®
GbE LAN chips (10/100/1000 Mbit)
Expansion Slots 1 x M.2 Socket 1 connector for an Intel
®
wireless module (CNVI)
1 x full size Mini PCIe connector (MSATA_MPCIE)
* The MINI_PCIE connector can also be used as an MSATA connector.
(The Mini PCIe connector conforms to PCI Express 2.0 standard.)
Storage Interface Integrated in the SoC:
- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe x4/x2 SSD support)
(M2)
- 1 x SATA 6Gb/s connector
- 1 x MSATA connector (MSATA_MPCIE)
USB Integrated in the SoC:
- 2 x USB 3.1 Gen 1 ports on the back panel
- 4 x USB 2.0/1.1 ports available through the internal USB headers
Internal
Connectors
1 x DC-In power connector
1 x system fan header
1 x SATA 6Gb/s connector
1 x M.2 Socket 3 connector
1 x SATA power connector
1 x front panel header
2 x USB 2.0/1.1 headers
4 x serial port headers
4 x serial port power select jumpers
1 x GPIO header
1 x LVDS header
1 x LVDS drive voltage jumper (LCD_VCC)
1xatpaneldisplayheader(FPD)
1xatpaneldisplayswitchheader(MON_SW)
- 6 -
