- 4 -
GA-SBC4100 Motherboard Layout
(Note) The chip is on the back of the motherboard.
Box Contents
5 GA-SBC4100 motherboard 5 One SATA power cable
5 Motherboard driver disk 5 One COM port cable
5 Two SATA cables 5 One DC In power cable
5 One heat spreader
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
GA-SBC4100
SATA_PWR
LVDS
M_BIOS
SYS_FAN
FPD
F_USB2
F_PANEL
LCD_VCC
COMB
MON_SW
RUSB30
Intel
®
Gemini Lake SoC N4100
(Note)
SPKR_CTRL
COMD
BAT
SPEAKER
COMA COMC
M2
SATA3 0
HP_MIC
CODEC
iTE
®
Super I/O
(Note)
LAN1
LAN2
DDR4_2
DDR4_1
Realtek
®
GbE
LAN
DOUBLE
HDMI
CLR_CMOS
30
COMA_PW COMB_PW COMC_PW COMD_PW
SMBUS I2C GPIO
MSATA_MPCIE
80
DCIN_PWR
HS
F_USB1
CNVI
Realtek
®
GbE
LAN
