20/73
TECHNICAL SPECIFICATIONS
EWAD~T-SLB
MODEL
EWAD520T-
SL B2
EWAD580T-
SL B2
EWAD700T-
SL B2
EWAD800T-
SL B2
EWAD940T-
SL B2
COOLING PERFORMANCE
Capacity - Cooling
kW
523
576
701
810
936
Capacity control - Type
Stepless
Stepless
Stepless
Stepless
Stepless
Capacity control - Minimum capacity %
12.5
12.5
12.5
12.5
12.5
Unit power input - Cooling
kW
171
189
234
266
308
EER
3.06
3.04
3.00
3.04
3.04
ESEER
3.95
4.05
3.87
3.89
3.82
IPLV
5.38
5.49
4.93
4.55
4.69
CASING
Colour *
Material *
IW
GPSS
IW
GPSS
IW
GPSS
IW
GPSS
IW
GPSS
DIMENSIONS
Height
mm
2540
2540
2537
2537
2537
Width
mm
2258
2258
2282
2282
2282
Length
mm
5030
5030
5976
5976
6876
WEIGHT
Unit Weight
kg
4860
4860
5527
5525
5858
Operating Weight
kg
5030
5030
5825
5825
6188
WATER HEAT EXCHANGER
Type *
S&T
S&T
S&T
S&T
S&T
Water Volume
l
170
164
315
240
289
Water flow rate
l/s
25.0
27.6
33.6
38.7
44.8
Water pressure drop
kPa
43.6
60.4
51.4
32.4
39.5
Insulation material *
CC
CC
CC
CC
CC
AIR HEAT EXCHANGER
Type *
MCH
MCH
MCH
MCH
MCH
FAN
Type *
ON-OFF
ON-OFF
ON-OFF
ON-OFF
ON-OFF
(DPT)
(DPT)
(DPT)
(DPT)
(DPT)
Drive *
On/Off
On/Off
On/Off
On/Off
On/Off
Diameter
mm
800
800
800
800
800
Nominal air flow
l/s
55214
55214
66257
66257
77300
Quantity
No.
10
10
12
12
14
Speed
rpm
900
900
900
900
900
Motor input
kW
16.7
16.7
20.0
20.0
23.4
COMPRESSOR
Type
Asymm
Asymm
Asymm
Asymm
Asymm
Single Screw
Single Screw
Single Screw
Single Screw
Single Screw
Oil charge
l
32.0
32.0
34.0
34.0
42.0
Quantity
No.
2
2
2
2
2
SOUND LEVEL**
Sound Power - Cooling
dB(A)
97
97
96
96
97
Sound Pressure level@1m distance - dB(A)
77
77
75
75
76
Cooling
REFRIGERANT CIRCUIT
Refrigerant type
R134a
R134a
R134a
R134a
R134a
Refrigerant charge
kg
66
67
93.6
93.6
109.2
N. of circuits
No.
2
2
2
2
2
PIPING CONNECTIONS
Evaporator water inlet/outlet
mm
139.7
139.7
168.3
168.3
168.3
All the performances (Cooling capacity, unit power input in cooling and EER) are based on the following conditions: evaporator 12.0/7.0°C; ambient
35.0°C, unit at full load operation; operating fluid: Water ; fouling factor = 0.
(*) IW: Ivory White; GPSS: Galvanized and Painted Steel Sheet; PHE: Plate Heat Exchanger; S&T: Single Pass Shell & Tube; MCH: Microchannel; CC:
Closed Cell; DPT: Direct Propeller Type; DOL: Direct On Line - VFD: Inverter - BRS: Brushless
(**) Sound power level (referred to evaporator 12/7°C, ambient 35°C full load operation) are measured in accordance with ISO 9614 and Eurovent 8/1
for Eurovent certified units. The certification refers only to the overall sound power level, the sound pressure is calculated from the sound power level and
are for information only and not considered binding.
The minimum capacity indicated is referred to unit operating at standard Eurovent conditions.
Dimensions and weights are for indication only and not
considered binding. Before designing the installation, consult the official drawings available from the factory at request. All the data are referred to
standard unit without options. Data are subject to change without notice.
