ELECTRICAL SPECIFICATIONS
EWAD~T-SRB
MODEL
EWADH18T
- SR B3
EWADC19T
- SR B3
EWADC20T
- SR B2
EWADC21T-
SR B2
POWER SUPPLY
Phases
No.
3
3
3
3
Frequency
Hz
50
50
50
50
Voltage
V
400
400
400
400
Voltage tolerance Minimum %
-10%
-10%
-10%
-10%
Voltage tolerance Maximum %
10%
10%
10%
10%
UNIT
Maximum inrush current
A
1199
1250
1301
1301
Nominal running current cooling
A
1070
1115
1161
1201
Maximum running current
A
1230
1293
1357
1420
Maximum current for wires sizing
A
1349
1419
1489
1558
FANS
Nominal running current cooling
A
34.6
37.4
40.3
43.2
COMPRESSORS
Phases
No.
3
3
3
3
Voltage
V
400
400
400
400
Voltage tolerance Minimum %
-10%
-10%
-10%
-10%
Voltage tolerance Maximum %
10%
10%
10%
10%
Maximum running current
A
398
459
459
459
Starting method
Y-Δ
Y-Δ
Y-Δ
Y-Δ
Fluid: Water
Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%.
Maximum starting current: starting current of biggest compressor + current of the other compressors at maximum load + fans current at maximum load.
In case of inverter driven units, no inrush current at start up is experienced.
Nominal current in cooling mode is referred to the following conditions: evaporator 12/7°C; ambient 35°C; compressors + fans current.
Maximum running current is based on max compressor absorbed current in its envelope and max fans absorbed current
Maximum unit current for wires sizing is based on minimum allowed voltage
Maximum current for wires sizing: (compressors full load ampere + fans current) x 1,1.
The data are referred to the standard unit without options.
For the electrical data of the hydronic kit refer to "Options technical data"
All data are subject to change without notice. Please refer to unit nameplate data.
