![Daikin EWAD420T-XSB2 [41/81] Compressors](/img/pdf.png)
Daikin EWAD420T-XSB2 [41/81] Compressors
![Daikin EWADH15T-XSB3 [41/81] Compressors](/views2/1675931/page41/bg29.png)
35/73
ELECTRICAL SPECIFICATIONS
EWAD~T-SLB
MODEL
EWAD700T-
SR B2
EWAD800T-
SR B2
EWAD940T-
SR B2
EWADC10T-
SR B2
EWADH10T-
SR B2
EWADC11T-
SR B2
POWER SUPPLY
Phases
No.
3
3
3
3
3
3
Frequency
Hz
50
50
50
50
50
50
Voltage
V
400
400
400
400
400
400
Voltage tolerance Minimum %
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum %
10%
10%
10%
10%
10%
10%
UNIT
Maximum inrush current
A
567
638
693
701
766
786
Nominal running current cooling
A
376.73
431.76
499.71
554.32
592.7
629.99
Maximum running current
A
478
523
605
659
693
750
Maximum current for wires sizing
A
524
573
663
722
760
822
FANS
Nominal running current cooling
A
17.28
17.28
20.16
20.16
20.16
23.04
COMPRESSORS
Phases
No.
3
3
3
3
3
3
Voltage
V
400
400
400
400
400
400
Voltage tolerance Minimum %
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum %
10%
10%
10%
10%
10%
10%
Maximum running current
A
274
274
398
452
398
452
Starting method
Y-Δ
Y-Δ
Y-Δ
Y-Δ
Y-Δ
Y-Δ
MODEL
EWADH12T-
SR B2
EWADH13T-
SR B2
EWADH14T-
SR B2
EWADH15T-
SR B3
EWADH16T-
SR B3
EWADC17T-
SR B3
POWER SUPPLY
Phases
No.
3
3
3
3
3
3
Frequency
Hz
50
50
50
50
50
50
Voltage
V
400
400
400
400
400
400
Voltage tolerance Minimum %
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum %
10%
10%
10%
10%
10%
10%
UNIT
Maximum inrush current
A
868
914
922
1057
1143
1199
Nominal running current cooling
A
720.93
755.84
790.74
864
909
984
Maximum running current
A
820
876
933
961
1091
1160
Maximum current for wires sizing
A
900
962
1023
1054
1196
1273
FANS
Nominal running current cooling
A
23.04
25.92
28.8
31.7
34.6
34.6
COMPRESSORS
Phases
No.
3
3
3
3
3
3
Voltage
V
400
400
400
400
400
400
Voltage tolerance Minimum %
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum %
10%
10%
10%
-10%
10%
10%
Maximum running current
A
398
452
452
310
398
398
Starting method
Y-Δ
Y-Δ
Y-Δ
Y-Δ
Y-Δ
Y-Δ
Fluid: Water
Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%.
Maximum starting current: starting current of biggest compressor + current of the other compressors at maximum load + fans current at maximum load.
In case of inverter driven units, no inrush current at start up is experienced.
Nominal current in cooling mode is referred to the following conditions: evaporator 12/7°C; ambient 35°C; compressors + fans current.
Maximum running current is based on max compressor absorbed current in its envelope and max fans absorbed current
Maximum unit current for wires sizing is based on minimum allowed voltage
Maximum current for wires sizing: (compressors full load ampere + fans current) x 1,1.
The data are referred to the standard unit without options.
For the electrical data of the hydronic kit refer to "Options technical data"
All data are subject to change without notice. Please refer to unit nameplate data.
