TECHNICAL SPECIFICATIONS
EWAD~T-XRB
MODEL
EWADC13T-
XR B2
EWADH13T-
XR B2
EWADC14T-
XR B2
EWADH15T-
XR B3
EWADH16T-
XR B3
EWADC17T-
XR B3
COOLING PERFORMANCE
kW
1.273
1.355
1.413
1.563
1.661
1.789
Capacity control - Type
Stepless
Stepless
Stepless
Stepless
Stepless
Stepless
Capacity control - Minimum capacity %
12.5
12.5
12.5
12.5
12.5
12.5
kW
426
452
490
528
559
596
EER
2.99
3.00
2.88
2.96
2.97
3.00
ESEER
3.96
3.96
3.88
3.94
3.85
3.90
IPLV
4.65
4.69
4.62
4.51
4.53
4.56
CASING
Colour *
Material *
IW
GPSS
IW
GPSS
IW
GPSS
IW
GPSS
IW
GPSS
IW
GPSS
DIMENSIONS
mm
2537
2537
2537
2537
2537
2537
mm
2282
2282
2282
2282
2282
2282
mm
9576
10476
10476
11409
12309
13209
WEIGHT
kg
8706
9071
9085
11225
11491
11361
kg
9198
9552
9555
12096
12362
11883
WATER HEAT EXCHANGER
Type *
S&T
S&T
S&T
S&T
S&T
S&T
l
492
481
470
871
871
953
l/s
60.9
64.8
67.6
74.8
79.5
85.6
kPa
34.4
38.5
48.2
43.0
48.1
52.0
Insulation material *
CC
CC
CC
CC
CC
CC
AIR HEAT EXCHANGER
Type *
MCH
MCH
MCH
MCH
MCH
MCH
FAN
Type *
ON-OFF
ON-OFF
ON-OFF
ON-OFF
ON-OFF
ON-OFF
(DPT)
(DPT)
(DPT)
(DPT)
(DPT)
(DPT)
Drive *
On/Off
On/Off
On/Off
On/Off
On/Off
On/Off
mm
800
800
800
800
800
800
l/s
86954
95649
95649
104344
113040
121735
No.
20
22
22
24
26
28
rpm
700
700
700
700
700
700
kW
17.4
19.1
19.1
20.9
22.6
24.4
COMPRESSOR
Type
Asymm
Asymm
Asymm
Asymm
Asymm
Asymm
Single Screw
Single Screw
Single Screw
Single Screw
Single Screw
Single Screw
l
50.0
50.0
50.0
75.0
75.0
75.0
No.
2
2
2
3
3
3
SOUND LEVEL**
dB(A)
93
93
93
97
97
97
Sound Pressure level@1m distance - dB(A)
71
71
71
75
74
74
Cooling
REFRIGERANT CIRCUIT
Refrigerant type
R134a
R134a
R134a
R134a
R134a
R134a
kg
156
171.6
171.6
187
203
218
No.
2
2
2
3
3
3
mm
219.1
219.1
219.1
273
273
273
All the performances (Cooling capacity, unit power input in cooling and EER) are based on the following conditions: evaporator 12.0/7.0°C; ambient
35.0°C, unit at full load operation; operating fluid: Water ; fouling factor = 0.
(*) IW: Ivory White; GPSS: Galvanized and Painted Steel Sheet; PHE: Plate Heat Exchanger; S&T: Single Pass Shell & Tube; MCH: Microchannel; CC:
Closed Cell; DPT: Direct Propeller Type; DOL: Direct On Line - VFD: Inverter - BRS: Brushless
(**) Sound power level (referred to evaporator 12/7°C, ambient 35°C full load operation) are measured in accordance with ISO 9614 and Eurovent 8/1
for Eurovent certified units. The certification refers only to the overall sound power level, the sound pressure is calculated from the sound power level and
are for information only and not considered binding.
The minimum capacity indicated is referred to unit operating at standard Eurovent conditions.
Dimensions and weights are for indication only and not
considered binding. Before designing the installation, consult the official drawings available from the factory at request. All the data are referred to
standard unit without options. Data are subject to change without notice.
