TECHNICAL SPECIFICATIONS
72/73
Refrigerant circuit The unit shall have two independent refrigerant circuits. The circuit shall include as
standard: electronic expansion device piloted by unit’s microprocessor control, compressor discharge shut-
off valves, liquid line shut-off valve, economizer circuit, sight glass with moisture indicator, replaceable
filter drier, charging valves, high pressure switch, high and low pressure transducers, oil pressure
transducer and insulated suction line.
Low sound unit configurations (on request) The unit compressor shall be connected with unit’s metal
base frame by rubber antivibration supports to prevent the transmission of vibrations to all metal unit
structure, in order to control the unit sound.
The chiller shall be provided with an acoustical compressor enclosure. This enclosure shall be realized
with a light, corrosion resisting aluminum structure and metal panels. The compressor sound -proof
enclosure shall be internally fitted with flexible, multi -layer, high density materials.
Hydronic kit options (on request) The hydronic module shall be integrated in the chiller chassis without
increasing its dimensions and includes the following elements: centrifugal pump with motor protected by a
circuit breaker installed in control panel, water filling system with pressure gauge, safety
valve, drain valve.
The hydronic module shall be assembled and wired to the control panel.
The water piping shall be protected against corrosion and freezing and insulated to prevent
condensation.
A choice of two pump types shall be available:
-
in-line single pump
-
in-line twin pumps.
Master/Slave the unit shell be able to operate in Master / Slave mode in order to be connected
with other similar unit (up to 4). The master unit shall manage the slaves units connected in series on the
hydraulic plant with the aim of optimize the running hours of each compressor and to balance running hours
and the load between the units.
Electrical control panel Power and control shall be located in the main panel that will be
manufactured to ensure protection against all weather conditions.
The electrical panel shall be IP54 and (when opening the doors) internally protected against possible
accidental contact with live parts.
The main panel shall be fitted with a main switch interlocked door that shuts off power supply when
opening.
The power section will include compressors and fans protection devices, fans starters and control
circuit power supply.
Controller The controller will be installed as standard and it will be used to modify unit set-points and
check control parameters.
A built -in display will shows chiller operating status plus temperatures and pressures of water,
refrigerant and air, programmable values, set-points.
A sophisticated software with predictive logic, will select the most energy efficient combination
of compressors, EEXV and condenser fans to keep stable operating conditions to maximize chiller
energy efficiency and reliability.
The controller will be able to protect critical components based on external signals from its system (such
as motor temperatures, refrigerant gas and oil pressures, correct phase sequence, pressure switches
and evaporator). The input coming from the high pressure switch cuts all digital output from the
controller in less than 50ms, this will be an additional security for the equipment.
Fast program cycle (200ms) for a precise monitoring of the system.
Floating point calculations supported for increased accuracy in P/T conversions.
