D-EOMWC01405-18EN
14/47
EWWD_DZ – EWWH_DZ
Stage Off @
30%
0…100%
Fan speed for stage down of one fan
Valve/Vfd Control
None
None, Valve Setpoint, Valve
Stage, VFD Stage, Valve
SP/VFD Stage
Regulation method
Valve Type
NC to Tower
NC to tower, NO to Tower
Type of bypass valve to tower
Valve/VFD SP=
18.33°C
15.6…48.9°C
Setpoint for bypass valve and vfd
Valve Min Pos
10%
0…100%
Valve minimum position
Valve Max Pos
90%
0…100%
Valve maximum position
Vfd Min Sp
10.0%
0.0…49.0 %
Setpoint for minimum percentage of Vfd Speed
Vfd Max Sp
100.0%
55.0…100.0%
Setpoint for maximum percentage of Vfd Speed
Valve Prop Gain
10.0
0.0…50.0
Proportional Gain of PID condensation controller
Valve Der Time
1s
0...180s
Derivative Time of PID condensation controller
Valve Int Time
600s
0…600s
Integral Time of PID condensation controller
Vfd Manual Speed
20.0%
0.0…100.0%
Setpoint for Vfd manual speed
4.2.5 Master/Slave
All data and parameters available in this sub-menus are related to the Master Slave function. Refer to Master Slave manual
for more details.
Setpoint/Sub-Menu
Default
Range
Description
Data
-
Submenu Data. This link is available only on the Master unit
Options
-
Submenu Options. This link is available only on the Master unit
Thermostat Ctrl
-
Submenu Thermostat Ctrl. This link is available only on the
Master unit
Timers
-
Submenu Timers. This link is available only on the Master unit
Standby Chiller
-
Submenu Standby Chiller. This link is available only on the
Master unit
Disconnect Unit
No
No,Yes
Parameter to disconnect the unit by the Master Slave system.
When this parameter is set to Yes the unit follows all local
settings.
4.2.5.1 Data
In this menu are collected all main data related to Master Slave function.
Setpoint/Sub-Menu
Default
Range
Description
Next On=
-
-,Master, Slave 1, Slave 2,
Slave 3
Display next chiller that will be starts
Next Off=
-
-,Master, Slave 1, Slave 2,
Slave 3
Display next chiller that will be stopped
Standby=
-
-,Master, Slave 1, Slave 2,
Slave 3
Display the actual standby chiller
Switch Date
-
dd/mm/yyyy
Display the day in which the standby chiller will be cycled
Switch Time
-
hh:mm:ss
Display at which time of the switch day the standby chiller will
be cycled
Plant Load=
-
0%...100%
Display the actual plant load
Avg EWT
-
-
Display the actual average entering water temperature value
Common EWT
-
-
Display the actual common entering water temperature value
Mst State=
-
Off, On, Alarm, Comm Err
Display the actual state of the Master
Sl1 State=
-
Off, On, Alarm, Comm Err
Display the actual state of the Slave 1
Sl2 State=
-
Off, On, Alarm, Comm Err
Display the actual state of the Slave 2
Sl3 State=
-
Off, On, Alarm, Comm Err
Display the actual state of the Slave 3
Mst Standalone=
-
No, Yes
Display if the standalone mode if active on the Master
Sl1 Standalone
-
No, Yes
Display if the standalone mode if active on the Slave 1
Sl2 Standalone
-
No, Yes
Display if the standalone mode if active on the Slave 2
Sl3 Standalone
-
No, Yes
Display if the standalone mode if active on the Slave 3
Mst Load=
-
0%...100%
Display the actual load of the Master
Sl1 Load=
-
0%...100%
Display the actual load of the Slave 1
Sl2 Load=
-
0%...100%
Display the actual load of the Slave 2
Sl3 Load=
-
0%...100%
Display the actual load of the Slave 3
Mst LWT=
-
-
Display the Master leaving water temperature
Sl1 LWT=
-
-
Display the Slave1 leaving water temperature
Sl2 LWT=
-
-
Display the Slave2 leaving water temperature
Sl3 LWT=
-
-
Display the Slave3 leaving water temperature
Mst EWT=
-
-
Display the Master entering water temperature
Sl1 EWT=
-
-
Display the Slave1 entering water temperature
Sl2 EWT=
-
-
Display the Slave2 entering water temperature
Sl3 EWT=
-
-
Display the Slave3 entering water temperature
Mst Hrs=
-
-
Master running hours
Sl1 Hrs=
-
-
Slave 1 running hours
Sl2 Hrs=
-
-
Slave 2 running hours
Sl3 Hrs=
-
-
Slave 3 running hours
Mst Starts=
-
-
Master number of starts
