EWWD_DZ – EWWH_DZ
D-EOMWC01405-18EN
17/47
Unit Current=
100.0A
Current Limit Mode (optional) - Unit current reading
Current Limit=
800A
Current Limit Mode (optional) - Active Current limit
Flex Current Lm=
Disable
Disable, Enable
Flexible Current Limit Enable
Current Lim Sp=
800A
0…2000A
Current Limit Mode Current limit setpoint
Setpoint Reset=
None
None, 4-20mA,
Return
Setpoint Reset Type
Max Reset=
5.0°C
0.0…10.0°C
Setpoint Reset Mode - Max Reset of water temp. setpoint
Start Reset DT=
5.0°C
0.0…10.0°C
Setpoint Reset Mode - Evaporator DT at which no reset is applied
Softload En=
Disable
Disable, Enable
Soft Load Mode Enable
Softload Ramp=
20min
1…60min
Soft Load Mode - Duration of the Softload ramp
Starting Cap=
40.0%
20.0…100.0%
Soft Load Mode - Starting capacity limit for Softload
4.2.10 Controller IP setup
The Microtech ® III controller has an embedded web server showing a replica of the onboard HMI screens. To access to
this additional web HMI can be required to adjust the IP settings to match the settings of the local network. This can be
done in this page. Please contact your IT department for further information on how to set the following setpoints.
To activate the new settings a reboot of the controller is required, this can be done with the Apply Changes setpoint.
The controller also supports DHCP, in this case the name of the controller must be used.
Setpoint/Sub-Menu
Default
Range
Description
Apply Changes=
No
No, Yes
When Yes, it save changes made on settings and reboot the controller
DHCP=
Off
Off, On
When On, Enable DHCP to automatically obtain an IP address
Act IP=
-
Active IP address
Act Msk=
-
Active Subnet mask
Act Gwy=
-
Active Gateway
Gvn IP=
-
Given IP address (it will become the active)
Gvn Msk=
-
Given Subnet mask
Gvn Gwy=
-
Given Gateway
PrimDNS
-
Primary DNS
SecDNS
-
Secondary DNS
Name
-
Controller Name
MAC
-
Controller MAC Address
Check with IT Department on how to set these properties in order to connect the Microtech III to the local network.
4.2.11 Daikin on Site
This menu allows to the user to enable the communication with Daikin cloud DoS (Daikin on Site) . This option requires
that the controller has access to internet. Please contact your service organization for more details.
Setpoint/Sub-Menu
Default
Range
Description
Comm Start=
Off
Off, Start
Command to enable the communication
Comm State=
-
-
IPErr
Init
InitReg
Reg
RegErr
Descr
Connected
Communication state.
The communication is established only if this parameter displays Connected
Cntrlr ID=
-
-
Controller ID. This parameter is helpful to identify the specific controller in DoS
Remote Update=
Disable
Disable,
Enable
Allow the application update from Daikin on Site.
4.2.12 Menu Password
It is possible to keep the User level always active to avoid to enter the User password. To do this the Password Disable
setpoint shall be set to On.
Setpoint/Sub-Menu
Default
Range
Description
Pwd Disable
Off
Off, On
Menu for Circuit #1
4.3 Active Setpoint
This link jumps to the page “Tmp Setpoint”. This page resumes all chiller water temperature setpoints (limits and active
setpoint will depend on the operating mode selected).
Setpoint/Sub-Menu
Default
Range
Description
Cool LWT 1=
7.0°C
4.0…15.0°C (cool mode)
-8.0…15.0°C (cool w/ glycol mode)
Primary cooling setpoint
Cool LWT 2=
7.0°C
4.0…15.0°C (cool mode)
-8.0…15.0°C (cool w/ glycol mode)
Secondary cooling setpoint (see 3.6.3)
Ice LWT=
-4.0°C
-8.0…4.0°C
Ice setpoint (ice banking with on/off mode)
