Daikin EWWH490DZXEA2 [15/47] Options
![Daikin EWWH490DZXEA2 [15/47] Options](/views2/1676634/page15/bgf.png)
EWWD_DZ – EWWH_DZ
D-EOMWC01405-18EN
15/47
Setpoint/Sub-Menu
Default
Range
Description
Sl1 Starts=
-
-
Slave 1 number of starts
Sl2 Starts=
-
-
Slave 2 number of starts
Sl3 Starts=
-
-
Slave 3 number of starts
4.2.5.2 Options
This menu allows to set main parameter of Master Slave function
Setpoint/Sub-Menu
Default
Range
Description
Master Priority=
1
1…4
Start Up / Shut Down priority of the chiller Master
Priority = 1 highest priority
Priority = 4 lowest priority
Slave 1 Priority=
1
1…4
Start Up / Shut Down priority of the chiller Slave 1
Priority = 1 highest priority
Priority = 4 lowest priority
Slave 2 Priority=
1
1…4
Start Up / Shut Down priority of the chiller Slave 2.
Priority = 1 highest priority
Priority = 4 lowest priority
This menu is visible only if the parameter M/S Num Of Unit
has been configured at least with value 3
Slave 3 Priority=
1
1…4
Start Up / Shut Down priority of the chiller Slave 3.
Priority = 1 highest priority
Priority = 4 lowest priority
This menu is visible only if the parameter M/S Num Of Unit
has been configured at least with value 4
Master Enable=
Enable
Enable Disable
This parameter allows to enable or disable locally the Master
Chiller
Control Mode=
Complete
Partial
Complete
Parameter to select the Partial or Complete control mode
Partial On/Off control
Complete On/Off + Capacity control
Control Tmp=
Leaving
Entering
Leaving
Parameter to define the controlled temperature
Entering - Thermoregulations is based on the Average
Entering Water Temperature (AEWT)
Leaving - Thermoregulation is based on the Common
Leaving Water Temperature (CLWT)
4.2.5.3 Thermostat Ctrl
This page resumes all thermostat control parameter of Master Slave.
Setpoint/Sub-Menu
Default
Range
Description
Stage Up DT=
2.7°C
0.5…5.0°C
Offset respect the active setpoint for the unit startup.
Stage Dn DT =
1.5°C
0.5…5.0°C
Offset respect the active setpoint for the unit shutdown.
Dead Band =
0.2
0.1 - Min(Stage UP DT, Stage Dn
DT)
Dead Band respect the active setpoint within which the
load/unload command are no longer generated
Threshold=
60%
30...100%
Threshold of load that have to reach all units running before
start of a new chiller
Stage Up Time=
5min
0min…20min
Minimum time between the start of two chillers
Stage Dn Time=
5min
0min…20min
Minim time between the stop of two chillers
Min Evap Tmp=
4.0
-18…30°C
Minimum Evaporator leaving water temperature
4.2.5.4 Timers
Setpoint/Sub-Menu
Default
Range
Description
Stage Up Timer=
-
-
Current delay for new chiller stage up
Stage Dn Timer=
-
-
Current delay for new chiller stage down
Clear Timers=
Off
Off
Reset
This command, visible only with service password, can be
used to reset the Stage Up/Dn Timer.
4.2.5.5 Standby Chiller
This menu allows to configure the standby chiller
Setpoint/Sub-Menu
Default
Range
Description
Standby Chiller=
No
No, Auto, Master, Slave 1, Slave 2,
Slave 3
Standby chiller selection
Cycling Type=
Time
Run Hours, Sequence
Cycling type of standby chiller if previous parameter Standby
Chiller is set as Auto
Interval Time=
7 Days
1…365
Define the interval time (expressed in day) for the cycling of
standby chiller
Switch Time=
00:00:00
00:00:00…23:59:59
Define the time within the day when will be performed the
switch of the standby chiller
Tmp Cmp=
No
No,Yes
Enabling of Temperature Compensation function
Tmp Comp Time=
120 min
0…600
Time constant of Temperature Compensation function
