Mechanical Specification (Single Unit)

Case No. 974A Unit:mm

Input / Output Connector Pin No. Assignment(CN501) : Postronic PCIM34W13M400A1

Pin No. Pin No. Pin No. Pin No. Pin No. Pin No.

1,2,3,4

13 18 23 28 33

11 16

5,6,7,8

14 19 24 29 34

12 17 22 27 32

Assignment Assignment Assignment Assignment Assignment Assignment Mating Housing

-V

+S A2 SCL +5V-AUX AC/N-V(signal)

+V(signal) -S A3 AC-OK +12V-AUX

DB A1 SDA FAN-FAIL AC/L

PV A0 A4 DC-OK GND-AUX

DA ON/OFF NC T-ALARM FG

Postronic

PCIM34W13F400A1

direction

Air flow

295

1 3 5 7 9 33

2 4 6 8 10 32 34

CN501

SVR1

2000W Front End Power Supply

R CP-2 000

s eri es

File Name:RCP-2 00 0-SPEC 20 13-11-01

SAFETY STANDARDS

WITHSTAND VOLTAGE

UL60950-1, TUV EN60950-1 approved

I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.7KVDC

ISOLATION RESISTANCE

MTBF

DIMENSION

PACKING

OTHERS

60.1K hrs min. MIL-HDBK-217F (25 )℃

295*127*41mm (L*W*H)

SAFETY &

EMC

(Note 4)

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH℃

2Kg;6pcs/13Kg/1.04CUFT

RCP-2000-12 RCP-2000-24MODEL RCP-2000-48

Compliance to EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN50082-2), heavy industry level, criteria A

Compliance to EN55022 (CISPR22) Conduction Class B, Radiation Class A ; EN61000-3-2,-3

NOTE

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.℃

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. Derating may be needed under low input voltages. Please check the static characteristics for more details.

6. Output of all the RCP-2000 modules are connected in parallel in the rack.

7. Under parallel operation of more than one rack connecting together, ripple of the output voltage may be higher than the SPEC at light load condition.

It will go back to normal ripple level once the output load is more than 10%.

EMC IMMUNITY

EMC EMISSION
