EFFICIENCY vs LOAD (48V Model)
LOAD
DERATING LOAD(%) VS INPUT VOLTAGE
INPUT / VOLTAGE
MODEL
RCP-2000-12
RCP-2000-24
RCP-2000-48
>180VAC
100%
100%
100%
115VAC
95%
80%
80%
100VAC
90%
75%
75%
90VAC
80%
65%
65%
Function Manual
1. Remote ON/OFF Control
The PSU can be turned ON/OFF together or separately by using the "Remote ON/OFF" function.
2.1 Remote Sense
The remote sense compensates voltage drop on the load wiring up to 0.5V.
Between ON/OFF and +5V-AUX
SW Open
SW Short
Output
OFF
ON
+5V-AUX
ON/OFF
RCP- 2000
17
29
SW
2. Voltage Drop Compensation
-V
+V
RCP- 2000
+S
-S
LOAD
-V
+V
14
15
Sense lines should be twisted in pairs
230VAC
Input only
-40 -25 0-10 15 30 50 60 70
20
40
60
50
80
100
(HORIZONTAL)
2000W Front End Power Supply
R CP-200 0
s eri es
File Name:RCP-2 000-SPEC 2013-11-0 1
Derating Curve Static Characteristics
INPUT VOLTAGE (VAC) 60Hz
90 100 115 180
24V,48V
12V
264
90
100
80
70
75
65
50
40
AMBIENT TEMPERATURE ( )℃
