Gigabyte C246-WU4 (rev. 1.0) [11/56] Center subwooferspeakerout orange

1-7 Back Panel Connectors

USB2.0/1.1Port

TheUSBportsupportstheUSB2.0/1.1specication.UsethisportforUSBdevices.

PS/2Keyboard/MousePort

Use this port to connect a PS/2 mouse or keyboard.

DisplayPort

DisplayPort delivers high quality digital imaging and audio, supporting bi-directional audio transmission.

DisplayPort can support both DPCP and HDCP 2.2 content protection mechanisms. It provides improved

visualssupportingRec.2020(WideColorGamut)andHighDynamicRange(HDR)forBlu-rayUHD

TheUSB3.1Gen2Type-AportsupportstheUSB3.1Gen2specicationandiscompatibletotheUSB

3.1Gen1andUSB2.0specication.UsethisportforUSBdevices.

USB Type-C

™

Port

ThereversibleUSBportsupportstheUSB3.1Gen2specicationandiscompatibletotheUSB3.1Gen

1andUSB2.0specication.UsethisportforUSBdevices.

RJ-45LANPort

The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following

describes the states of the LAN port LEDs.

Activity LED

USB3.1Gen1Port

TheUSB3.1Gen1portsupportstheUSB3.1Gen1specicationandiscompatibletotheUSB2.0

specication.UsethisportforUSBdevices.

Center/SubwooferSpeakerOut(Orange)

Use this audio jack to connect center/subwoofer speakers.

RearSpeakerOut(Black)

Use this audio jack to connect rear speakers.

OpticalS/PDIFOutConnector
