1-2 ProductSpecications
CPU LGA1151 package:
- Intel
®
Xeon
®
E series processors
-
9th and 8th Generation Intel
®
Core
™
processors/Intel
®
Pentium
®
processors/
Intel
®
Celeron
®
processors
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset Intel
®
C246 Express Chipset
Memory 4xDDR4DIMMsocketssupportingupto128GBofsystemmemory
Dual channel memory architecture
SupportforDDR42666/2400/2133MHzmemorymodules
SupportforECCUn-bufferedDIMM1Rx8/2Rx8memorymodules
Supportfornon-ECCUn-bufferedDIMM1Rx8/2Rx8/1Rx16memorymodules
SupportforExtremeMemoryProle(XMP)memorymodules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Integrated Graphics Processor-Intel
®
UHD Graphics support:
- 2xDisplayPorts,supportingamaximumresolutionof4096x2304@60Hz
* SupportforDisplayPort1.2version,HDCP2.2,andHDR.
Maximum shared memory of 1 GB
Audio Realtek
®
ALC1220-VB codec
* The back panel line out jack supports DSD audio.
HighDenitionAudio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN 2 x Intel
®
GbE LAN chips (10/100/1000 Mbit)
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x8 (PCIEX8)
* The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot
is populated, the PCIEX16 slot operates at up to x8 mode.
2 x PCI Express x16 slots, running at x4 (PCIEX4_1/PCIEX4_2)
* The PCIEX4_2 slot shares bandwidth with the M2M connector. The PCIEX4_2 slot
becomes unavailable when a PCIe SSD is installed in the M2M connector.
(All of the PCI Express slots conform to PCI Express 3.0 standard.)
1 x PCI slot
Multi-Graphics
Technology
Support for AMD Quad-GPU CrossFire
™
and 4-Way/3-Way/2-Way AMD
CrossFire
™
technologies
- 6 -
