Gigabyte C246-WU4 (rev. 1.0) [12/56] Linein sidespeakerout blue

• Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefromyour

device and then remove it from the motherboard.

• When removing the cable, pull it straight out from the connector. Do not rock it side to side to

prevent an electrical short inside the cable connector.

PleasevisitGIGABYTE'swebsitefordetailsonconguringtheaudiosoftware.

LineIn/SideSpeakerOut(Blue)

The line in jack. Use this audio jack for line in devices such as an optical drive, walkman, etc.

LineOut/FrontSpeakerOut(Green)

The line out jack. This jack supports audio amplifying function. For better sound quality, it is recommended

that you connect your headphone/speaker to this jack (actual effects may vary by the device being used).

MicIn/SideSpeakerOut(Pink)

The Mic in jack.

AudioJackCongurations:

Jack

Headphone/

2-channel

4-channel 5.1-channel 7.1-channel

Center/Subwoofer Speaker Out

a a

RearSpeakerOut

a a a

Line In/Side Speaker Out

Line Out/Front Speaker Out

a a a a

Mic In/Side Speaker Out

• If you want to install a Side Speaker, you need to retask either the Line in or Mic in jack to be Side

Speaker out through the audio driver.

• ToenableorconguretheaudioamplifyingfunctionfortheLineoutjack,pleaseaccesstheHD

Audio Manager application.

- 12 -
