ESIE11-05 Special Control
Functional Description 47
3.2 Defrosting Operation
To defrost the outdoor unit heat exchanger while in Evaporator, the defrost operation is
conducted to recover the heating capacity and runs a reverse cycle.
[Start conditions]
Heat exchange temperature Tb < Tdef (calculated by logic depending on Tamb) and the unit
has been at least 25 min in heating
or Te < 0°C the unit will be forced to take a defrost every 2 hours.
Furthermore, the heat transfer coefficient of the outdoor unit Evaporator is computed from Tc,
Te and compressor loads.
*1 Before switching over to defrost mode the unit closes the EXV for switch over.
*2 Before switching over to normal heating operations the unit closes the EXV for switch over.
* Actuators are based on EWYQ032BA.
Outdoor unit actuator
Defrost preparation
operation
Defrost operation Post Defrost operation
Compressor Upper limit control 176 Hz + ON + ON
124 Hz + OFF + OFF
2-steps increase/20sec.
till Pc - Pe>0.4 MPa
Outdoor unit fan
STEP7
or
STEP8
OFF STEP8
Four way valve ON OFF ON
Main electronic expansion valve
(EV1)
SH control → 480 pls 480 pls 55 pls
Subcooling electronic expansion
valve (EV2)
0 pls 0 pls 0 pls
Hot gas bypass valve (SVP) OFF OFF OFF
Accumulator oil return valve (SVO) ON ON ON
Ending conditions 170 sec.
• 12 min.
• Tb>11°C
• 10 sec.
• Pc - Pe>0.4MPa
Hydrobox expansion valve K11E *1 PI control *2
Hydrobox expansion valve K21E *1 PI control *2
or
or
