ESIE11-05 Field Setting from Outdoor Unit
Functional Description 69
* Running only on a STD compressor gives no regulation and has chance
on freeze up.
No. Setting item Description
38
Emergency
operation
(Setting for the
master unit
operation
prohibition in
EW*Q040BA,
050BA, 064BA
system)
Used to temporarily prohibit the applicable outdoor unit
from operating should there be any faulty part in
EW*Q040BA, 050BA, 064BA system. Since the
comfortable environment is extremely impaired, prompt
replacement of the part is required.
39
Emergency
operation
(Setting for the
slave operation
prohibition in
EW*Q040BA,
050BA, 064BA
system)
42
Emergency
operation
(prohibition of INV
compressor
operation)
If the INV compressor has a failure, used to run the
system only with STD compressor(s). This is a temporary
running of the system until the compressor is replaced,
thus making comfort extremely worse. Therefore, it is
recommended to replace the compressor as soon as
possible.
(Be noted this setting is not available on model
EW*Q016BA.)
