ASRock B460 Steel Legend [12/97] English
![ASRock B460 Steel Legend [12/97] English](/views2/1686816/page12/bgc.png)
English
6
BIOS
Feature
•
AMI UEFI Legal BIOS with multilingual GUI support
•
ACPI 6.0 Compliant wake up events
•
SMBIOS 2.7 Support
•
CPU Core/Cache, GT, DRAM, PCH, VCCST, VCCSA Volt-
age Multi-adjustment
Hardware
Monitor
•
Temperature Sensing: CPU, CPU/Water Pump, Chassis/Wa-
ter Pump Fans
•
Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water
Pump Fans
•
Quiet Fan (Auto adjust chassis fan speed by CPU tempera-
ture): CPU, CPU/Water Pump, Chassis/Water Pump Fans
•
Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/
Water Pump Fans
•
CASE OPEN detection
•
Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
VPPM, PCH, VCCST, VCCIO, VCCSA
OS
•
Microso® Windows® 10 64-bit
Certica-
tions
•
FCC, CE
•
ErP/EuP ready (ErP/EuP ready power supply is required)
Please realize that there is a certain risk involved with overclocking, including
adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using
third-party overclocking tools. Overclocking may aect your system’s stability, or
even cause damage to the components and devices of your system. It should be done
at your own risk and expense. We are not responsible for possible damage caused by
overclocking.
* For detailed product information, please visit our website:
http://www.asrock.com
