English
8
No. Description
1 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN1)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
4 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
5 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
6 RGB LED Header (RGB_LED2)
7 Addressable LED Header (ADDR_LED2)
8 ATX Power Connector (ATXPWR1)
9 Front Panel Type C USB 3.2 Gen1 Header (F_USB3_TC_1)
10 USB 3.2 Gen1 Header (USB3_5_6)
11 Chassis/Water Pump Fan Connector (CHA_FAN5/WP)
12 USB 2.0 Header (USB_5)
13 SATA3 Connector (SATA3_2)
14 SATA3 Connector (SATA3_3)
15 SATA3 Connector (SATA3_5)
16 SATA3 Connector (SATA3_4)
17 Chassis/Water Pump Fan Connector (CHA_FAN4/WP)
18 POST Status Checker (PSC)
19 SPI TPM Header (SPI_TPM_J1)
20 SATA3 Connector (SATA3_0)
21 SATA3 Connector (SATA3_1)
22 System Panel Header (PANEL1)
23 Chassis Intrusion and Speaker Header (SPK_CI1)
24 Clear CMOS Jumper (CLRMOS1)
25 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
26 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)
27 USB 3.2 Gen1 Header (USB3_3_4)
28 USB 2.0 Header (USB3_4)
29 RGB LED Header (RGB_LED1)
30 Addressable LED Header (ADDR_LED1)
31 Front Panel Audio Header (HD_AUDIO1)
32 underbolt AIC Connector (TB1)
33 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
