Fatal1ty Z77 Professional Series Motherboard
215
1.5 快速開關
本主板有三個快速開關 : 電源開關 , 復位開關與 C M OS 數據清除開關 , 可讓用戶快速
開啟 / 關閉或復位系統 , 或者清除 CMOS 中的數據。
電源開關 電源開關是一種快速開關 , 可
(PWRBTN)
讓用戶快速開啟 / 關閉系
( 見第 4 頁第 16 項 )
統。
復位開關 復位開關是一種快速開關 , 可
(RSTBTN)
讓用戶快復位系
( 見第 4 頁第 17 項 )
統。
CMOS 數據清除開關 CMOS 數據清除開關是一種快
(CLRCBTN)
速開關 , 可讓用戶快速清除
( 見第 5 頁第 18 項 )
CMOS 中的數據。
Power
Reset
簡體中文
