232
Fatal1ty Z77 Professional Series Motherboard
1.5 快速開關
本主機板有三個快速開關 : 電源開關 , 重置開關與 CMOS 數據清除開關 , 可讓用戶快
速開啟 / 關閉或重置系統 , 或者清除 CMOS 中的數據。
電源開關 電源開關是一種快速開關 , 可
(PWRBTN)
讓用戶快速開啟 / 關閉系
( 見第 4 頁第 16 項 )
統。
重置開關 重置開關是一種快速開關 , 可
(RSTBTN)
讓用戶快重置系統。
( 見第 4 頁第 17 項 )
CMOS 數據清除開關 CMOS 數據清除開關是一種快
(CLRCBTN)
速開關 , 可讓用戶快速清除
( 見第 5 頁第 18 項 )
CMOS 中的數據。
Power
Reset
繁體中文
