1.4 Motherboard Layout1.4 Motherboard Layout
1.4 Motherboard Layout1.4 Motherboard Layout
1.4 Motherboard Layout
1 PS2_USB_PWR1 Jumper 21 USB 2.0 Header (USB6_7, Blue)
2 ATX 12V Connector (ATX12V1) 22 USB 2.0 Header (USB8_9, Blue)
3 eSATAII Connector (eSATAII_BOTTOM) 23 SATAII Connector
4 775-Pin CPU Socket (SATAII_5 (Port4), Orange)
5 North Bridge Controller 24 Front Panel IEEE 1394 Header
6 CPU Fan Connector (CPU_FAN1) (FRONT_1394)
7 2 x 240-pin DDR2 DIMM Slots 25 DeskExpress Hot Plug Detection Header
(Dual Channel A: DDRII_1, DDRII_2; Yellow) (IR1)
8 2 x 240-pin DDR3 DIMM Slots 26 SPI BIOS Chip
(Dual Channel B: DDR3_A1, DDR3_B1; Green) 27 Floppy Connector (FLOPPY1)
9 2 x 240-pin DDR3 DIMM Slots 28 COM Port Header (COM1)
(Dual Channel C: DDR3_A2, DDR3_B2; Pink) 29 WiFi Header (WiFi)
10 IDE1 Connector (IDE1, Blue) 30 Front Panel Audio Header (HD_AUDIO1)
11 South Bridge Controller 31 Internal Audio Connector: CD1 (Black)
12 SATAII Connector (SATAII_1 (Port0), Red) 32 HDMI_SPDIF Header (HDMI_SPDIF1)
13 Clear CMOS Jumper (CLRCMOS1) 33 PCI Slots (PCI1 - 3)
14 Chassis Fan Connector (CHA_FAN1) 34 PCI Express 2.0 x16 Slot (PCIE3, Green)
15 SATAII Connector (SATAII_2 (Port1), Red) 35 PCI Express 2.0 x16 Slot (PCIE2, Green)
16 Chassis Speaker Header (SPEAKER 1) 36 PCI Express x1 Slot (PCIE1)
17 System Panel Header (PANEL1) 37 ATX Power Connector (ATXPWR1)
18 SATAII Connector (SATAII_3 (Port2), Red) 38 FSB1 / FSB2 / FSB3 Jumpers
19 SATAII Connector (SATAII_4 (Port3), Red) 39 eSATAII Connector (eSATAII_TOP)
20 SATAII Connector (SATAII_6 (Port5), Orange)
Intel
X48
Chipset
Intel
ICH9R
ATXPWR1
CD1
ATX12V1
1
PS2_USB_PWR1
Super
I/O
8Mb
BIOS
LAN
PHY
AUDIO
CODEC
PCIE2
CPU_FAN1
CMOS
Battery
DDR2 1066
Quad Core CPU
IDE1
CLRCMOS1
1
CHA_FAN1
FLOPPY1
1
HD_AUDIO1
HDLED RESET
PLED PWRBTN
SPEAKER1
1
PANE L1
1
WIFI
30.5cm (12.0 in)
24.4cm (9.6 in)
1
2
34
5
6
78
9
10
11
1
2
13
14
15
16
24
25 23
17
18
19
20
21
22
26
27
28
29
30
31
32
DDRII_1 (64 bit, 240-pin module)
DDR3_A1 (64 bit, 240-pin module)
RoHS
Dual Channel
1
HDMI_SPDIF1
IR1
1
SATAII_3(Port2)
SATAII_4(Port3)
FSB1600
FSB1
1
FSB3
1
FSB2
1
1
Top:
SIDE SPK
Center:
REAR SPK
Bottom:
CTR BASS
Top:
LINE IN
Center:
FRONT
Bottom:
MIC IN
PCI1
PCI2
PCI3
DDR3_A2 (64 bit, 240-pin module)
DDRII_2 (64 bit, 240-pin module)
DDR3_B1 (64 bit, 240-pin module)
DDR3_B2 (64 bit, 240-pin module)
USB6_7
11
USB8_9
11
SATAII_5(Port4)
SATAII_6(Port5)
SATAII_1(Port0)
SATAII_2(Port1)
DDR3 1600
ESATAII_BOTTOM
PS2
Mouse
PS2
Keyboard
USB 2.0
T: USB4
B: USB5
Top:
RJ-45
USB 2.0
T:USB0
B: USB1
33
34
35
36
37
38
PCIE3
PCIE1
ESATAII_TOP
PCI Express 2.0
FRONT_1394
11
VIA
VT6308S
Coaxial
SPDIF
Optical
SPDIF
Top:
IEEE 1394
Center:
ESATAII_TOP
Bottom:
ESATAII_BOTTOM
USB 2.0
T:USB2
B: USB3
1394a
COM1
1
39
