1.2 Specifications
Platform: ATX Form Factor (12.0-in x 7.0-in, 30.5 cm x 17.8 cm)
CPU: Socket 478 for Intel
®
Pentium
®
4/ Celeron
®
(Prescott, Northwood,
Willimate)processor
Chipsets: North Bridge:
Intel
®
845PE chipsets, standard FSB @ 533 / 400MHz,
Max. 800 MHz at overclocking mode (see CAUTION 1),
supports Hyper-Threading Technology (see CAUTION 2);
South Bridge:
Intel
®
ICH4
Memory: 2 DDR DIMM slots: DDR1 and DDR2
PC2100 (DDR266) / PC2700 (DDR333), Max. 2GB
PC3200 (DDR400) at overclocking mode, Max. 1GB
(see CAUTION 3);
IDE: IDE1: ATA 100 / Ultra DMA Mode 5;
IDE2: ATA 100 / Ultra DMA Mode 5;
Supports up to 4 IDE devices
Floppy Port: Supports up to 2 floppy disk drives
Audio: 5.1 channels AC’97 Audio
PCI LAN: Speed: 802.3u (10/100 Ethernet), supports Wake-On-LAN
Hardware Monitor: CPU temperature sensing (ASRock U-COP);
Chassis temperature sensing;
CPU overheat shutdown to protect CPU life
(ASRock U-COP)(see CAUTION 4);
CPU fan tachometer; Chassis fan tachometer;
Voltage monitoring: +12V, +5V, +3V, Vcore
PCI slots: 4 PCI slots with PCI Specification 2.2
AGP slot: 1 AGP slot, supports 1.5V, 4X AGP card (see CAUTION 5)
USB 2.0: 4 default USB 2.0 ports and one extra set of header for two
additional USB 2.0 ports upgrade (see CAUTION 6)
ASRock I/O
TM
: PS/2: 1 keyboard port / 1 mouse port;
1 RJ 45 port;
4 rear default USB 2.0 ports;
1 serial port: COM1; 1 parallel port: ECP/EPP support;
Audio Jack: Line Out / Line In / Microphone + 1 Game port
BIOS: AMI legal BIOS;Supports “Plug and Play”;
ACPI 1.1 compliance wake up events;
Supports jumperfree; SMBIOS 2.3.1 support;
CPU frequency stepless control
(only for advanced users’ reference, see CAUTION 7);
OS: Microsoft
®
Windows
®
98 SE / ME / 2000 / XP compliant
