NOTE

P4i45PE-C may be fine tuned to support higher CPU front side bus frequencies on certain

condition at over-clocking mode. Please refer to the tables below for the details.

CPU FSB Configuration Note

P4i45PE-C 800 MHz 1. Set the “FSB” jumper to “800” mode (see page 14).

2. Only support one DDR 400 memory module on DDR1

DIMM. (If it is set to DDR 400 mode, then it does not

support CL3 module.)

The Recommended Memory Modules lists for

P4i45PE-C motherboard.

FSB 800 MHz / DDR 400 Mode

DRAM SIZE TYPE CELL CELL NO. SINGLE SIDE /

VENDOR (MB) VENDOR DOUBLE SIDE

ADATA 512 DDR400 ADATA ADD8608A8A-58 DOUBLE SIDE

ADATA 256 DDR450 ADATA ADD8608A8A-4.58 SINGLE SIDE

ADATA 256 DDR400 WINBOND W942508CH-5 SINGLE SIDE

APACER 512 DDR400 PSC A2S56D30ATP DOUBLE SIDE

APACER 512 DDR400 SAMSUNG K4H560838D-TCCC DOUBLE SIDE

APACER 256 DDR400 INFINEON HYB25D256800BT-5 SINGLE SIDE

APACER 256 DDR400 SAMSUNG K4H560838D-TCCC SINGLE SIDE

INFINEON 256 DDR400 INFINEON HYB25D256800BT-5 SINGLE SIDE

INFINEON 128 DDR400 INFINEON HYB250256160BT-5 SINGLE SIDE

KINGMAX 512 DDR400 KINGMAX KDL3888P4EA-50 DOUBLE SIDE

KINGMAX 256 DDR400 KINGMAX KDL684T4AA-50 SINGLE SIDE

KINGSTON 256 DDR400 MOSEL V58C2256804SAT5 SINGLE SIDE

KINGSTON 256 DDR400 HYNIX HY5DU56822BT-D43 SINGLE SIDE

KINGSTON 256 DDR400 WINBOND W942508CH-5 SINGLE SIDE

MICRON 128 DDR400 MICRON 46V16M8 SINGLE SIDE

SAMSUNG 512 DDR400 SAMSUNG K4H560838D-TCCC DOUBLE SIDE

SAMSUNG 256 DDR400 SAMSUNG K4H560838E-TCC C SINGLE SIDE

TWINMOS 512 DDR400 M.tec TTD7608F8E50B DOUBLE SIDE

TWINMOS 256 DDR466 TWINMOS TMD7608F8E43B SINGLE SIDE

TWINMOS 256 DDR400 TWINMOS TMD7608F8E50B SINGLE SIDE

TWINMOS 256 DDR400 M.tec TTD7608F8E50B SINGLE SIDE

Since the memory types are changing rapidly,

please visit ASRock website (http://www.asrock.com/support/index.htm)

for the latest recommended memory support list.
