NOTE

P4i45GL may be fine tuned to support higher CPU front side bus frequencies on certain

condition. Please refer to the table below for the details.

CPU FSB Configuration Note

P4i45GL 533 MHz 1. It supports DDR266 memory module

at both DDR DIMM1 and DIMM2.

2. It supports DDR350 memory module

ONLY at DDR DIMM1.

3. To support DDR350, please set DDR350

in BIOS DRAM Frequency.

4. It supports CL=2 and CL=2.5 only.

The Recommended Memory Modules list for

P4i45GL motherboard.

FSB 533MHz / DDR350 Mode

DRAM SIZE TYPE CELL CELL NO. SINGLE SIDE /

VENDOR (MB) VENDOR DOUBLE SIDE

TWINMOS 256 DDR333 TWINMOS TMD7608F8E60B SINGLE SIDE

TWINMOS 256 DDR400 TWINMOS TMD7608F8E50B SINGLE SIDE

TWINMOS 512 DDR400 TWINMOS TMD7608F8E50B DOUBLE SIDE

TWINMOS 512 DDR400 M.TEC TTD7608F8E50B DOUBLE SIDE

ADATA 256 DDR400 WINBOND W942508CH-5 SINGLE SIDE

ADATA 256 DDR400 WINBOND W942508BH-5 SINGLE SIDE

ADATA 256 DDR400 ADATA ADD8608A8A-4.5B SINGLE SIDE

KINGMAX 256 DDR400 KINGMAX KDL388P4EA-50 SINGLE SIDE

KINGMAX 512 DDR400 KINGMAX KDL388P4EA-50 DOUBLE SIDE

KINGSTON 256 DDR333 MOSEL V58C2256804SAT6 SINGLE SIDE

KINGSTON 512 DDR333 INFINEON HYB25D256800BT-6 DOUBLE SIDE

MICRON 256 DDR333 MICRON 46V32M8-6TC SINGLE SIDE

MICRON 256 DDR400 MICRON 46V16M8 DOUBLE SIDE

INFINEON 128 DDR400 INFINEON HYB25D256800BT-5 SINGLE SIDE

INFINEON 256 DDR400 INFINEON HYB25D256800BT-5 SINGLE SIDE

TRANSCEND 256 DDR333 SAMSUNG K4H560838D-TCB3 SINGLE SIDE

Since the memory types are changing rapidly, please visit ASRock website

(http://www.asrock.com/support/index.htm) for the latest recommended memory support list.
