ASRock A320M-HDVP [13/70] English
![ASRock A320M-HDVP [13/70] English](/views2/1691296/page13/bgd.png)
English
8
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN1)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_A2)
4 ATX Power Connector (ATXPWR1)
5 USB 3.2 Gen1 Header (USB3_5_6)
6 USB 2.0 Header (USB_3_4)
7 USB 2.0 Header (USB_5_6)
8 SATA3 Connector (SATA3_3)
9 SATA3 Connector (SATA3_4)
10 SATA3 Connector (SATA3_1)
11 SATA3 Connector (SATA3_2)
12 System Panel Header (PANEL1)
13 Chassis Intrusion and Speaker Header (SPK_CI1)
14 Print Port Header (LPT1)
15 COM Port Header (COM2)
16 Chassis Fan Connector (CHA_FAN2)
17 Clear CMOS Header (CLRCMOS1)
18 Front Panel Audio Header (HD_AUDIO1)
19 SPI TPM Header (SPI_TPM_J1)
20 Chassis Fan Connector (CHA_FAN1)
