ASRock A320M-HDVP [7/70] Specifications
![ASRock A320M-HDVP [7/70] Specifications](/views2/1691296/page7/bg7.png)
English
2
1.2 Specications
Platform
•
Micro ATX Form Factor
•
Solid Capacitor design
CPU
•
Supports AMD Socket AM4 A-Series APUs (Bristol Ridge)
and Ryzen Series CPUs (Matisse, Picasso, Summit Ridge,
Raven Ridge and Pinnacle Ridge)
•
6 Power Phase design
•
Supports CPU up to 105W
Chipset
•
AMD Promontory A320
Memory
•
Dual Channel DDR4 Memory Technology
•
2 x DDR4 DIMM Slots
•
AMD Ryzen series CPUs (Matisse) support DDR4
3200/2933/2667/2400/2133 ECC & non-ECC, un-buered
memory*
•
AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4
3200+(OC)/2933(OC)/2667/2400/2133 ECC & non-ECC, un-
buered memory*
•
AMD Ryzen series CPUs (Picasso) support DDR4
2933/2667/2400/2133 non-ECC, un-buered memory*
•
AMD Ryzen series CPUs (Summit Ridge) support DDR4
3200+(OC)/2933(OC)/2667/2400/2133 ECC & non-ECC, un-
buered memory*
•
AMD Ryzen series CPUs (Raven Ridge) support DDR4
3200+(OC)/2933/2667/2400/2133 non-ECC, un-buered
memory*
•
AMD 7
th
Gen A-Series APUs support DDR4 2400/2133 non-
ECC, un-buered memory*
* For Ryzen Series CPUs (Picasso and Raven Ridge), ECC is only
supported with PRO CPUs.
* Please refer to Memory Support List on ASRock’s website for
more information. (http://www.asrock.com/)
* Please refer to page 21 for DDR4 UDIMM maximum
frequency support.
•
Max. capacity of system memory: 32GB
•
15μ Gold Contact in DIMM Slots
