ASRock A320M-HDVP [9/70] English
![ASRock A320M-HDVP [9/70] English](/views2/1691296/page9/bg9.png)
English
4
Audio
•
7.1 CH HD Audio (Realtek ALC887 Audio Codec) r.
•
Supports Surge Protection
•
ELNA Audio Caps
LAN
•
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
•
Realtek RTL8111H
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Rear Panel
I/O
•
1 x PS/2 Mouse Port
•
1 x PS/2 Keyboard Port
•
1 x Serial Port: COM1
•
1 x D-Sub Port
•
1 x DVI-D Port
•
1 x HDMI Port
•
2 x USB 2.0 Ports (Supports ESD Protection)
•
4 x USB 3.2 Gen1 Ports (Supports ESD Protection)
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jacks: Line in / Front Speaker / Microphone
Storage
•
4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
•
1 x Ultra M.2 Socket, supports M Key type 2242/2260/2280
M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up
to Gen3 x4 (32 Gb/s) (with Matisse, Picasso, Summit Ridge,
Raven Ridge and Pinnacle Ridge) or Gen3 x2 (16 Gb/s) (with
A-Series APU and Athlon 2xxGE series APU)*
* Supports NVMe SSD as boot disks
* Supports ASRock U.2 Kit
