60~75W Constant Current Mode LED Driver
ELG-75-C series
■ Features ■ Applications
■ Model Encoding
- C500ELG -
75
A
Output wattage
Series name
■ Description
ELG-75-C series is a 75W LED AC/DC driver featuring the constant current mode and
high voltage output. ELG-75-C operates from 100~305VAC and offers models with different
rated current ranging between 350mA and 1400mA. Thanks to the high efficiency up to 91%,
with the fanless design, the entire series is able to operate for -40 ~+85 case temperature under℃℃
free air convection. The design of metal housing and IP67/IP65 ingress protection level allows
this series to fit both indoor and outdoor applications. ELG-75-C is equipped with various function
options, such as dimming methodologies, so as to provide the optimal design flexibility for LED
lighting system.
Constant Current mode output
Metal housing design with functional Ground
Built-in active PFC function
<0.5WNo load / Standby power consumption
IP67 / IP65 rating for indoor or outdoor installations
Function options: output adjustable via potentiometer;
3 in 1 dimming (dim-to-off); Smart timer dimming; DALI
Typical lifetime>50000 hours
5 years warranty
LED street lighting
LED harbor lighting
LED bay lighting
LED greenhouse lighting
LED flood lighting
Type HL for use in Class I, Division 2
(Classified) location.hazardous
Rated output current (350/500/700/1050/1400mA)
Function options
Type
Blank
A
B
IP Level
IP67
IP65
IP67
Io fixed.
Io adjustable through built-in potentiometer.
3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance)
Function Note
In Stock
In Stock
In Stock
MM
110
IP67
IP65
Type HL
8
(for DA-Type only)
DA
Dx
D2
IP67
IP67
IP67
DALI control technology.
Built-in Smart timer dimming function by user request.
Built-in Smart timer dimming and programmable function.
In Stock
By request
In Stock
File Name:ELG-75-C-SPEC 2018-09-30
Input wiring type
Blank:2-wire input for standard model
-
{
3Y:3-wire input for standard model
IS 15885(Part 2/Sec13)
R-41027766
THOMAS SAMUEL
THOMAS SAMUEL
(for 700A/1050Aonly)
AB IP65
Io adjustable through built-in potentiometer &
3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance)
In Stock
