MECHANICAL SPECIFICATION
60~75W Constant Current Mode LED Driver
ELG-75-C series
CASE NO.: 243A Unit:mm
85
20
169
180
156
45.8
63
300±20300±20
35
35.5
※ Blank-Type
tc
: Max. Case Temperature
※ A-Type
AC/L(Brown)
AC/N(Blue)
169
180
156
45.8
63
300±20
300±20
35
35.5
44.25
21
4- 4.5ψ
4- 4.5ψ
Vo+(Brown)
Vo-(Blue)
AC/L(Brown)
AC/N(Blue)
tc
85
20
tc
: Max. Case Temperature
tc
Vo+(Brown)
Vo-(Blue)
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
File Name:ELG-75-C-SPEC 2018-09-30
