※ B/DA/D2-Type
169
180
156
45.8
63
300±20
300±20
35
35.5
4- 4.5ψ
AC/L(Brown)
AC/N(Blue)
60~75W Constant Current Mode LED Driver
ELG-75-C series
85
20
tc
: Max. Case Temperature
tc
* DIM+ for B-Type
DA+ for DA-Type
PROG+ for D2-Type
* *DIM- for B-Type
DA- for DA-Type
PROG- for D2-Type
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
DIM-(Black)**
DIM+( )*Gray
Vo+(Brown)
Vo-(Blue)
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
File Name:ELG-75-C-SPEC 2018-09-30
※ AB-Type
44.25
21
169
180
156
45.8
63
300±20
300±20
35
35.5
4- 4.5ψ
AC/L(Brown)
AC/N(Blue)
85
20
tc
: Max. Case Temperature
tc
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
DIM-(Black)
DIM+( )Gray
Vo+(Brown)
Vo-(Blue)
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
