ASRock 939A8X-M [24/37] 2 4 2 4 2 4 2 4
![ASRock 939A8X-M [24/37] 2 4 2 4 2 4 2 4](/views2/1692496/page24/bg18.png)
2424
2424
24
CPU Host Frequency
While entering setup, BIOS auto detects the present CPU host frequency of
this motherboard. The actual CPU host frequency will show in the following
item.
Boot Failure Guard
Enable or disable the feature of Boot Failure Guard.
Spread Spectrum
This item should always be [Disabled] for better system stability.
Cool ‘n’ Quiet
Use this item to enable or disable AMD’s Cool ‘n’ Quiet
TM
technology.
Processor Maximum Multiplier
It will display Processor Maximum Multiplier for reference.
Processor Maximum Voltage
It will display Processor Maximum Voltage for reference.
Multiplier/Voltage Change
This item is set to [Auto] by default. If it is set to [Manual], you may adjust the
value of Processor Multiplier and Processor Voltage. However, it is recom-
mended to keep the default value for system stability.
BIOS SETUP UTILITY
CPU Configuration
If AUTO, FID/VID will
be left at the rated
frequency/voltage. If
Manual, FID/VID will
be set based on User
Selection in Setup.
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Actual Frequency (MHz)
CPU Host Frequency
[200]
[Auto]
Processor Maximum Multiplier
Processor Maximum Voltage
Processor Multiplier
Processor Voltage
Memory Clock
Flexibility Option
Burst Length
CAS Latency (CL)
TRCD
[x8]
[1.500V]
[Auto]
[8 Beats]
[Auto]
[Auto]
[Disabled]
x11
1.550 V
Multiplier/Voltage Change
[Manual]
Boot Failure Guard
Spread Spectrum
Cool'n'Quiet
[Enabled]
[Disabled]
[Enabled]
BIOS SETUP UTILITY
Select DRAM commands
and address timing.
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Cool'n'Quiet
[Enabled]
Processor Maximum Multiplier
Processor Maximum Voltage
Processor Multiplier
Processor Voltage
Memory Clock
Flexibility Option
Burst Length
CAS Latency (CL)
TRCD
TRAS
TRP
[x8]
[1.500V]
[Auto]
[8 Beats]
[Auto]
[Auto]
[Auto]
[Auto]
[Disabled]
x11
1.550 V
Multiplier/Voltage Change
[Manual]
MA Timing
[2T]
