66
66
6
1.21.2
1.21.2
1.2
SpecificationsSpecifications
SpecificationsSpecifications
Specifications
Platform: Micro ATX Form Factor: 9.6-in x 8.6-in, 24.4 cm x 21.8 cm
CPU: 939-Pin Socket Supporting AMD Athlon
TM
64 / 64FX Processor
Supports AMD’s Cool ‘n’ Quiet
TM
Technology (see CAUTION 1)
Chipset: Bridge: ULi (ALi) M1689, FSB @ 1000 MHz
Memory: 4 x DDR DIMM Slots:
4 DIMMs support PC3200 (DDR 400) / PC2700 (DDR 333) /
PC2100 (DDR 266), Max. 4GB
IDE: IDE1: ATA 133 / Ultra DMA Mode 6
IDE2: ATA 133 / Ultra DMA Mode 6
Support up to 4 IDE devices
Serial ATA: 2 x SATA connectors
Support 1.5Gb/s data transfer rate
Floppy Port: Supports up to 2 floppy disk drives
Audio: 7.1 channels AC’97 Audio
LAN: Speed: 802.3u (10/100 Ethernet), supports Wake-On-LAN
Hardware Monitor: CPU temperature sensing
Motherboard temperature sensing
CPU overheat shutdown to protect CPU life
(ASRock U-COP)(see CAUTION 2)
CPU fan tachometer
Chassis fan tachometer
Voltage monitoring: +12V, +5V, +3.3V, Vcore
PCI Slots: 3 x PCI slots, PCI specification 2.3
AGP Slot: 1 x AGP slot
Supports 1.5V, 8X / 4X AGP card (see CAUTION 3)
USB 2.0: 8 x USB 2.0 ports:
4 ready-to-use USB 2.0 ports on the I/O panel,
plus 2 on-board headers supporting 4 extra USB 2.0 ports
(see CAUTION 4)
ASRock 8CH I/O: 1 PS/2 Mouse Port, 1 PS/2 Keyboard Port
1 Serial Port: COM1
1 Parallel Port (ECP/EPP Support)
4 Ready-to-Use USB 2.0 Ports
1 RJ-45 Port
Audio Jack: Side Speaker / Rear Speaker / Central/Bass /
Line In / Front Speaker / Microphone
(see CAUTION 5)
