ASRock K7VM3 [5/30] Specifications
![ASRock K7VM3 [5/30] Specifications](/views2/1692531/page5/bg5.png)
5
1.2 Specifications
Platform: Micro ATX form factor (9.6" x 7.5", 24.4 x 19.1 cm)
CPU: Supports Socket A (462 pins) for
AMD Athlon
TM
/ Athlon
TM
XP/ Duron
TM
processor
Chipsets: North Bridge: VIA KM266Pro, FSB@200/266/333 MHz
South Bridge: VIA VT8235, supports USB 2.0, ATA 133
Memory: 2 DDR DIMM slots: DDR1 and DDR2
PC2100 (DDR266) / PC2700 (DDR333), Max. 2GB
IDE: IDE1: ATA 133 / Ultra DMA Mode 6;
IDE2: ATA 133 / Ultra DMA Mode 6;
Can connect up to 4 IDE devices
Floppy Port: Supports 2 floppy disk drives
Audio: 5.1channels AC’97 Audio
LAN: Speed: 802.3u (10/100 Ethernet), supports Wake-On-LAN
Hardware Monitor: CPU temperature sensing;
Chassis temperature sensing;
CPU overheat shutdown to protect CPU life
(ASRock U-COP)(see CAUTION 1);
Voltage monitoring: +12V, +5V, +3V, Vcore;
CPU fan tachometer; Chassis fan tachometer
PCI slots: 2 slots with PCI Specification 2.2
AGP slot: 1 AGP slot, supports 1.5V, 4X AGP card (see CAUTION 2)
AMR slot: 1 slot, supports AMR modem card
USB 2.0: 4 default USB 2.0 ports and 1 extra set of header for two
additional USB 2.0 ports upgrade (see CAUTION 3)
ASRock I/O
TM
: PS/2: 1 keyboard port / 1 mouse port;
1 RJ 45 port; 4 rear default USB 2.0 ports;
1 VGA port; 1 parallel port: ECP/EPP support;
Audio Jack: Line Out / Line In / Microphone + Game port
BIOS: AMI legal BIOS; Supports “Plug and Play”;
ACPI 1.1 compliance wake up events;
SMBIOS 2.3.1 support;
CPU frequency stepless control
(only for advanced users’ reference, see CAUTION 4)
OS: Microsoft
®
Windows
®
98 SE / ME / 2000 / XP compliant
