1.4 ASRock I/O
TM
1 Parallel port 2 RJ-45 port
3 Game port 4 Microphone (Pink)
5 Line In (Light Blue) 6 Line Out (Lime)
7 USB 2.0 ports 8 VGA port
9 PS/2 keyboard port (Purple) 10 PS/2 mouse port (Green)
11
2
3
1098 765
4
