3.3 Installing the CPU Fan and Heatsink
2
CPU_
FAN
3
1
DeskMini 310 series supports both Intel CPU Box Fan (65W) and third-party CPU fan
cooler. Please note that the DeskMini 310 series chassis has 52mm height limitation for the
CPU fan cooler.
