ASRock DeskMini 310 Series [8/63] Deskmini 310 series
![ASRock DeskMini 310 Series [8/63] Deskmini 310 series](/views2/1692950/page8/bg8.png)
2 3
English
DeskMini 310 series
Front I/O
•
Power Button (with power LED & HDD LED)
•
1 x USB 3.1 Gen1 (Type-A), 1 x USB 3.1 Gen1 (Type-C), 1 x
Headphone/Headset Jack , 1 x MIC-In
Rear I/O
•
1 x VGA , 1 x HDMI, 1 x DP, 1 x USB 3.1 Gen1, 1 x USB 2.0, 1
x LAN, 1 x DC-In Jack (for DeskMini 310 series)
•
1 x VGA , 1 x HDMI, 1 x DP, 2 x USB 3.1 Gen1, 1 x LAN, 1 x
DC-In Jack (for DeskMini 370 & 360 series)
Storage
•
2 x SATA3 6.0 Gb/s with Power Connectors, support NCQ,
AHCI and Hot Plug
•
1 x Ultra M.2 Socket, support M Key type 2280 M.2 SATA3 6.0
Gb/s module and M.2 PCI Express module up to Gen3 x4 (32
Gb/s)*
* Supports NVMe SSD as boot disks
Onboard
Connectors
•
1 x USB 2.0 Header
•
1 x COM Port Header (only for DeskMini 310/COM)
•
1 x Front Panel Header
•
2 x CPU_Fan Connectors
•
1 x DC-In Jack (Supports 19V Power Adapters)
•
1 x Internal Speaker Header (4-Pin)
•
1 x Audio Header (4-Pin)
•
1 x MONO Speaker Header
Drive Bays
•
2 x 2.5" HDD or SSD
Power
Adapter
•
120W/19V Power Adapter
Operation
Temp.
•
0~35°C
Please realize that there is a certain risk involved with overclocking, including adjusting
the setting in the BIOS, applying Untied Overclocking Technology, or using third-party
overclocking tools. Overclocking may aect your system’s stability, or even cause damage to
the components and devices of your system. It should be done at your own risk and expense.
We are not responsible for possible damage caused by overclocking.
